D-Plate Backer Plate
C$44.00
Sale
23-SA1039
In stock
Brand: Super Anchor Safety
Product Information
D-Plate Hoisting/Lifting Anchors
D-Plate anchors are 3rd party tested and engineered for hoisting/lifting applications.
Specifications
- No.1037-G5M/S5M min. tensile strength 10,000lb
- No.1301-G10M/S10M min. tensile strength 20,000lb
- 3,600lb proof load certificate provided for each D-plate
- 6”x6”x3/8” base plate
Lift Hook Compatibility
The lift hook crown must rotate freely when connected to the loop top.
Installation
- Bolt attach w/1/2” grd. 5, 8, or 18-8sst.
- Field weld or concrete embedment
Compliance
ANSI Z359.18-17 Type A/T
Intertek D-Plate 09-2020 test reports*
*Test equipment max. peak force 20,000lb
DH Glabe & Assoc. engineering report
Reports are available on request.
Instruction Manuals
